HS-4000 4.5 inch


  • * 2/5.0MP AHD/IP.
  • * 18/33/36X Zoom.
  • * 6pcs Array IR 60M.
  • * Medium Speed Dome Camera.
  • * Range:Pan:0º~360º , Tilt:-0º~93º .
  • * Speed:Pan:0~60°/s , Tilt:0~45º/s.
  • * POE/Audio/Alarm/TF Card Optional.
  • * IP66 Weatherproof Standard.
  • * Transient Voltage 6000V Thunder Protect.
  • * Support Remotely Upgrade.
  • * PWM Infrared Light Technology.


* 2.0MP/5.0MP Analog/IP.

* 18/33/36X Optical Zoom.

* With 6pcs Array IR Led.

* Effect IR Distance 60M.

* Medium Speed Dome Camera.

* Range:Pan:0º~360º , Tilt:-0º~93º .

* Speed:Pan:0~60°/s , Tilt:0~45º/s.

* POE/Audio/Alarm/TF Card Optional.

* IP66 Weatherproof Standard.

* Transient Voltage 6000V Thunder Protect.

* Minimum illumination of 0.00 Lux (Led on).

* Support Remotely Upgrade.

* PWM Infrared Light Technology.

Installation Note:

(1) Do not use this product falls on the ground or the strong tapping;

(2) Unless the instructions, otherwise do not disassemble the machine itself;

(3) Before use, please determine whether the power supply for the specified voltage;

(4) Aim to avoid strong light (such as sunlight, lighting, etc), otherwise easy to cause a bright or light phenomenon (this is not a fault), will also affect the Chipset life;

(5) Avoid in damp, dusty, hot, cold, strong electromagnetic radiation, etc;

(6) If found abnormal situation, please unplug the power and contact the local distributor.

(7) Lightning protection earth wire should be grounded to the nearest.

Model No.F4M-4018F4M-4033THS-4018THS-4036TAF-4018
Video EncodeAHD/TVI/CVI/XVI/CVBSH.265H.265
Image Sensor1/3" SONY CMOS1/3" SONY CMOS1/3" CMOS
ChipsetNVP2441H+SONY IMX323(3D NR)Hi3516CV300+IMX323Hi3516D+AR5521
Resolution2.0 Megapixels2.0 Megapixels5.0 Megapixels
Illumination0.01 Lux/F1.20.01 Lux/F1.20.01 Lux/F1.20.01 Lux/F1.2
Optical LENS18X(5.35MM~96.3MM)33X(4.9MM~161.7MM)18X(5.35MM~96.3MM)36X(4.6MM-165MM)18X(5.35MM~96.3MM)
SpeedMedium SpeedMedium SpeedMedium SpeedMedium SpeedMedium Speed
IR LEDMedium Speed:6pcs Array IR Led,IR Distance 60 Meters
Rotation Range/SpeedRange:Pan:0º~360º,Tilt:0º~90º  Speed: Pan:0~60°/s,Tilt:0~45º/s
Preset Points220pcs presetsdwell time 01-60s interval available
Guard Tours3 groups( Max.16 points, dwell time user selectable)
AB Scan Range/SpeedAny point in range:-45º~40º and 0º~200º/1-9 grades
Thunder ProtectTransient Voltage 6000V Thunder Protect of Network,POE....
IR board InterfaceOriginal PWM infrared light technology, uniform brightness, low calorific value,
The service life of infrared lamp is longer than 3 times.
IP Specification
Video ProcessingH.265 Video encoding, support dual-stream AVI format, code stream 0.05Mpbs ~ 3Mpbs
Network InterfaceRJ45 10/100M Adaptive Ethernet Interface
OptionalPoE (IEEE802.3af)/Audio(G711,PCM )TF CARD(MAX 128G)
FunctionSupport IE WEB configuration, OSD, real-time video transmission, support the motion detecting, JPEG Screen shot,
 remote monitoring client software CMS, Mobile phone monitoring (iPhone, Windows Mobile, Android), provide SDK
S/N Ratio>=50dB
ES1/50 - 1/10,0000S
Working Temp.Outdoor: -40~+70
Voltage InputPower 12V DC 3A
Package SizeW295mm*D280mm*H170mm
WeightGross Weight:2.24KG(With Bracket)
